Direct nanoengineering and lithographic patterning of optically anisotropic thin films
Journal article   Peer reviewed

Direct nanoengineering and lithographic patterning of optically anisotropic thin films

Ian Hodgkinson, Qi hong Wu, Matthew Arnold and Richard Blaikie
Microelectronic engineering, Vol.57, pp.833-836
01/09/2001
Handle:
https://hdl.handle.net/10523/34525

Abstract

Birefringence Chiral film Lithography Reactive ion etching Thin film
Biaxial and chiral thin films formed by oblique vapour deposition are patterned using standard photolithography. In one example 5 μm wide half-wave plates are fabricated by reactive ion etching a biaxial silicon film.
